Description

It is widely used for personal care products, bio-pharmaceutical products, food, paints, ink, nanometre materials, petrochemical Industry, printing and Dyeing Auxiliaries, paper industry, pesticide fertilizer, plastic rubber, power electronics, other fine chemicals, etc. It is especially suitable for good emulsion effect for materials which are of high matrix viscosity or high solid content.

To meet different products’ requirement, we have several designs for customers to choose: glass types, stainless steel type, top homogenizing, bottom homogenizing, and internal-external circular homogenizing etc;

It is facilized with VFD for speed adjustment;

Double mechanical sealing, max 28000rpm speed, the highest shear fineness can reach 2.5-5um;

Vacuum defoaming makes the material meet the requirements of asepsis; vacuum is adopted especially good for powder materials;

3 layers of high quality stainless steel (SS304 or SS316);

Jacket can be used for heating or cooling the materials;

Heating can be of steam or electrical;

Mirror polishing meets GMP requirement;

2L, 5L, 10L, 20L, etc are available for meeting different capacity requirements.

Product Features

Suitable: Cream, Paste, Ointment, Lotion, Gel. Conditioner, Milk, Sauce, Syrup, etc.

Fineness: 2.5~5um

Capacity: 2L, 5L, 10L, 20L, etc

Type: Glass type or SS type

Material: All parts contact with material are of SS316L or SS304

Homogenizer Speed: 10000~28000RPM adjustable

Vacuum Pump: included

Scrapping type paddle: 0~180RPM

VFD: included

Lifting: Electrical Control

Vacuum:-0.07Mpa

Heating: Electrical Heating or Steam Heating

Water Jacket: Included for heating or cooling use

Auxiliary Parts: Product filter, Perfume hopper , air filter, etc

Polishing Class: Mirror GMP
